ML Series Single Phase Dual-Capacitor Induction Motor Wholesaler

Brief Introduction

MC/MLMY series aluminum housing single phase capacitor asynchronous motor adopts the latest international design with the selected qualified die casted aluminum-alloy materials, which meet and conform to the IEC standard in entirety.

MC series motor is with 1 capacitor, which is capacitor-start type, which can supply high starting torque.

ML series motor is with 2 capacitors, which are capacitor-start and capacitor-run. They can supply high starting torque and long time stable running performances

MY series motor is with 1 capacitor, which is capacitor-run type, which can supply long time stable running performances.

MC/MLMY series motors have good performance, such as high safety, low noise, little vibration, reliable operation, stable running and convenient maintenance.

They are light weight, small volume and simple construction.

The foot can be removable, and various mounting methods are available.

Standard Features

Type: Single Phase Asynchronous Motor

Rated output: 0.12~4kW, 0.16~5.5HP

Rated voltage: 110V, 115V, 220V, 230V, 240V

Rated frequency (Speed):

50Hz (Synchronous speed 3000/1500 r/min),

60Hz (Synchronous speed 3600/1800 r/min)

No. of poles: 2, 4 Pole

Mounting methods: B14, B3, B34, B35, B5

Material of housing: Aluminum-alloy

Frame size: 63~112 frame

Ambient Temperature: -20~40°C

Altitude: 1000 m.a.s.l

Humidity: ≦90%

Protection Class: IP44, IP54, IP55

Insulation Class: B (130℃), F (155℃)

Temp. Rising: ΔT=80°K (B class)

Cooling: IC411 (Totally-enclosed, fan-cooled)

Working Duty: S1 (Continuous)

Customized frame size/power

Shaft: Special dimensions, double shaft end, tapered, hollow as per request

Service Factor: 1.15 or above

Insulation Class: H (180℃)

Ambient temperature: Above 40 °C (on request)

Altitude: ＞1000M (on request)

Bearing: SKF, FAG brand

Others

Compressor
Pump
Refrigerator
Medical Apparatus
Painting Machine
Small Machine Tools
Compressor
Pump
Refrigerator
Medical Apparatus
Painting Machine
Small Machine Tools

ML Series Single Phase Dual-capacitor Induction Motor
Type	Rated		Rated Current			Rated	Efficien	Power	Rated	Ist/In	Tst/Tn	Tmax/Tn	Noise	Weight
	power		at			speed	cy	factor	torque
			110V	220V	240V
	(kW)	(HP)	(A)	(A)	(A)	(r/min)	(η%)	(cosφ)	(N.m)	(times)	(times)	(times)	dB(A)	(kg)
Synchronous Speed 3000 r/min = 2-poles (50Hz)
ML631-2	0.18	0.25	2.89	1.44	1.32	2710	63	0.9	0.63	5.8	2.5	1.6	70	4
ML632-2	0.25	0.34	3.95	1.97	1.81	2710	64	0.9	0.88	5.3	2.5	1.6	73	4.5
ML711-2	0.37	0.5	5.56	2.78	2.55	2780	65	0.93	1.27	5.6	2.5	1.8	75	6
ML712-2	0.55	0.75	7.91	3.95	3.62	2790	68	0.93	1.88	5.3	2.5	1.8	76	6.5
ML801-2	0.75	1	10.2	5.09	4.67	2800	72	0.93	2.56	6.2	2.5	1.8	76	9
ML802-2	1.1	1.5	14.7	7.36	6.75	2810	73	0.93	3.74	5.7	2.5	1.8	79	10
ML90S-2	1.5	2	19.8	9.91	9.08	2810	74	0.93	5.10	5.8	2.5	1.8	84	13
ML90L-2	2.2	3	28.4	14.2	13.0	2810	75	0.94	7.48	5.5	2.5	1.8	84	14
ML100L-2	3	4	37.3	18.6	17.1	2830	77	0.95	10.1	6.2	2.5	1.7	88	24
ML112M-2	4	5.5	47.8	23.9	21.9	2850	80	0.95	13.4	6.8	2.5	1.7	90	34
Synchronous Speed 1500 r/min = 4-poles (50Hz)
ML631-4	0.12	0.16	2.20	1.10	1.01	1350	55	0.9	0.85	5.7	2.5	1.6	64	4
ML632-4	0.18	0.25	3.25	1.62	1.49	1350	56	0.9	1.27	5.5	2.5	1.6	64	4.5
ML711-4	0.25	0.34	4.21	2.10	1.93	1380	60	0.9	1.73	5.0	2.5	1.7	66	6
ML712-4	0.37	0.5	5.93	2.97	2.72	1380	63	0.9	2.56	5.3	2.5	1.7	68	6.5
ML801-4	0.55	0.75	8.42	4.21	3.86	1400	66	0.9	3.75	5.0	2.5	1.8	71	9.5
ML802-4	0.75	1	11.0	5.49	5.03	1410	69	0.9	5.08	5.7	2.5	1.8	71	10.5
ML90S-4	1.1	1.5	15.1	7.57	6.94	1410	71	0.93	7.45	5.5	2.5	1.8	74	13.5
ML90L-4	1.5	2	20.1	10.0	9.21	1400	73	0.93	10.2	5.7	2.5	1.8	79	14.5
ML100L1-4	2.2	3	29.1	14.5	13.3	1430	74	0.93	14.7	5.4	2.5	1.8	79	24
ML100L2-4	3	4	39.1	19.6	17.9	1440	75	0.93	19.9	5.9	2.5	1.8	83	29
ML112M-4	4	5.5	48.9	24.4	22.4	1440	80	0.93	26.5	6.7	2.5	1.7	86	33
